The Rentricity NSF-Edge:
Certified Flow-to-Wire™, Pump-as-Turbine Systems
Site Assessment
Click on Specs for details
Why NSF Certification?
Rentricity and the Cornell Pump Company (Cornell) have worked together since 2012 to provide the highest level of safety certification for its hydro-turbine product line (link to press release). This exclusive partnership makes Rentricity the global sole-source provider of NSF 61/372 Pump-as-Turbines (PAT) for In-Conduit Hydropower manufactured in the United States by the Cornell Pump Company.
The National Safe Drinking Water Act (SDWA) prohibits the use of any in-pipe device that is not lead free (less than 8 percent lead). Congress amended the SDWA in 1996 requiring that water-facing components meet lead-leaching performance standards of the National Sanitation Foundation (NSF) and the American National Standards Institute (ANSI). NSF/ANSI Standard 61 has since been adopted by 49 states and Canada.
The Water Quality Association recognition marks an important milestone for Rentricity and Cornell , both committed to assuring safety and quality for Owner/Client who apply our clean energy recovery in-conduit hydropower solutions. The NSF/ANSI standard was awarded following stringent and extensive qualification of requirements for the control of potential human health effects from products that contact consumable drinking water, food & beverage, and pharmaceutical applications.
A Closer Look at NSF for In-Conduit Hydropower
Flow-to-Wire™ Certified Drinking Water System Components & Certified Lead-free, In-conduit Hydropower Turbines
The Rentricity Flow-to-Wire Turbine NSF/ANSI 61 & 372 Certification includes the following:
- Confirms compliance with individual state drinking water requirements as well as those of the 2014 Amendment of the U.S. Federal Safe Water Drinking Act.
- NSF/ANSI 372 certifies that each product has a weighted average lead content of 0.25% or less.
- Cornell Pump’s manufacturing facility in Clackamas, OR has been successfully audited and certified by the Water Quality Association.
- Selected materials approved by NSF/ANSI 61 & 372 Certification
- 45 States & 8 Provinces require certification with 5 states requiring compliance
NSF/ANSI/CAN 61 - 2021
Drinking Water System Components – establishes the minimum health effects requirements for the chemical contaminants and impurities that are indirectly imparted to drinking water from products, components, and materials used in drinking water systems.
This Standard does not establish performance, taste and odor, or microbial growth support requirements for drinking water systems products, components, or materials. Drinking Water Treatment Products certified to NSF/ANSI 61 have not been tested or evaluated for contaminant reduction performance. Contaminant reduction testing and certification claims shall be evaluated via the industry’s residential drinking water treatment standards.
NSF/ANSI/CAN 372
This establishes a standardized methodology for the determination and verification of product compliance with a maximum weighted average lead content requirement of 0.25%. With the exception of those products exempted in the Safe Drinking Water Act of the United States, all products certified to NSF/ANSI/CAN 61 must also be evaluated to the requirements of NSF/ANSI/CAN 372.
On September 1, 2020, the U.S. Environmental Protection Agency (EPA) published the final regulation “Use of Lead Free Pipes, Fittings, Fixtures, Solder, and Flux for Drinking Water,” which requires that manufacturers or importers certify that their products meet a 0.25% weighted average lead content for products conveying or dispensing drinking water.
Selecting a Flow-to-Wire In-Conduit Hydropower Turbine for your Project
Rentricity can supply Flow-to-Wire (F2W) Pump-as-Turbines (PAT) for a variety of applications within solid pipe infrastructure. Twenty-two (22) units have been certified by the Water Quality Association to the NSF safe drinking water and low lead standard. Another 16 are in various stages of review and can be certified in an expedited fashion. The water flow/head (elevation) charts and links below illustrate will provide you a way to select a F2W PAT for a project site or sites you are reviewing.
1200 RPM, Flow-to-Wire, Turbines
NSF Certified, Pending NSF Certification
Model: 3TR1 - 1200 RPM
Output Range: 4 to 7kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Model: 3TR2 - 1200 RPM
Output Range: 5 to 25kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 3TR3 - 1200 RPM
Output Range: 5 to 25kW
Model: 4TR2 - 1200 RPM
Output Range: 5 to 15kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Model: 4TR3 - 1200 RPM
Output Range: 5 to 20kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Model: 4TR4 - 1200 RPM
Output Range: 15 to 35kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR1 - 1200 RPM
Output Range: 2 to 11kW
Model: 5TR1A - 1200 RPM
Output Range: 4 to 14kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR2 - 1200 RPM
Output Range: 10 to 60kW
Model: 5TR3 - 1200 RPM
Output Range: 10 to 45kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR4 - 1200 RPM
Output Range: 15 to 65kW
Model: 5TR5A - 1200 RPM
Output Range: 3 to 13kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR1 - 1200 RPM
Output Range: 5 to 25kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR2 - 1200 RPM
Output Range: 15 to 100kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR3 - 1200 RPM
Output Range: 10 to 60kW
Model: 6TR4 - 1200 RPM
Output Range: 10 to 80kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 8TR3 - 1200 RPM
Output Range: 10 to 110kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 10TR1 - 1200 RPM
Output Range: 10 to 60kW
Model: 10TR2 - 1200 RPM
Output Range: 15 to 95kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
1800 RPM, Flow-to-Wire, Turbines
NSF Certified, Pending NSF Certification
Model: 3TR1 - 1800 RPM
Output Range: 5 to 20kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 3TR2 - 1800 RPM
Output Range: 8 to 55kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 3TR3 - 1800 RPM
Output Range: 10 to 90kW
Model: 4TR2 - 1800 RPM
Output Range: 5 to 60kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 4TR3 - 1800 RPM
Output Range: 5 to 60kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 4TR4 - 1800 RPM
Output Range: 15 to 80kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 4TR5 - 1800 RPM
Output Range: 3 to 12kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR1 - 1800 RPM
Output Range: 5 to 35kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR1A - 1800 RPM
Output Range: 5 to 40kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR2 - 1800 RPM
Output Range: 25 to 200kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR4 - 1800 RPM
Output Range: 30 to 225kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR5 - 1800 RPM
Output Range: 5 to 20kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 5TR5A - 1800 RPM
Output Range: 10 to 35kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR1 - 1800 RPM
Output Range: 20 to 90kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR2 - 1800 RPM
Output Range: 40 to 300kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR3 - 1800 RPM
Output Range: 25 to 200kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 6TR4 - 1800 RPM
Output Range: 50 to 225kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 8TR3 - 1800 RPM
Output Range: 50 to 380kW
Standard Integrated Configuration Turbine: Ductile Iron/Close Coupled Seal: Mechanical Shaft Seal Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase Optional Features Safe Water/Low Lead NSF 61/372 Certification Horizontal (frame mount) or Vertical (support stand) Configuration Stainless Steel Total Enclosed Fan-Cooled Generator (TEFC) Fresh Water/Finished Consumable Water Single phase, 600 volt 3 phase generators 1200 and 1800 RPM Generators Speed Sensing (Tachometer)Model: 10TR1 - 1800 RPM
Output Range: 50 to 130kW
Model: 10TR2 - 1800 RPM
Output Range: 50 to 375kW
Standard Integrated Configuration
Turbine: Ductile Iron/Close Coupled
Seal: Mechanical Shaft Seal
Generator: Standard Open Drip Proof (ODP) 480 volt - 3 phase
Optional Features
Safe Water/Low Lead NSF 61/372 Certification
Horizontal (frame mount) or Vertical (support stand) Configuration
Stainless Steel
Total Enclosed Fan-Cooled Generator (TEFC)
Fresh Water/Finished Consumable Water
Single phase, 600 volt 3 phase generators
1200 and 1800 RPM Generators
Speed Sensing (Tachometer)
